Master PostgreSQL Self-Hosting Guide (Dokploy+VPS)

Version: Postgres 17.7 (Server) | Postgres 18.1 (Local Client)
Status: ✅ SSL Enabled | ✅ WAL Logical Enabled | ✅ Multi-Tenant Ready

This guide documents the complete setup and operation of a production-ready, multi-tenant PostgreSQL instance hosted on Oracle Cloud (OCI), deployed via Dokploy, and secured with SSL.

It also covers proper schema-level permissions required for modern stacks like Next.js, Prisma, and migrations.

0. Prerequisites

• OCI VM (Ubuntu/Debian recommended)

• Dokploy installed

• Cloudflare DNS

• Docker & Docker Compose

• PostgreSQL client locally (psql)

1. Cloudflare DNS Configuration 🌐

To expose PostgreSQL safely over a custom domain, Cloudflare proxy must be disabled.

DNS Record

• Type: A

• Name: pg

• IPv4: 193.123.91.169

• Proxy Status: ☁️ DNS Only (Grey Cloud)

⚠️ Important
Cloudflare’s Orange Cloud blocks non-HTTP ports like 5432.

2. Firewall & Network Security 🔐

Postgres must be allowed at both OCI level and OS level.

A. OCI Security List

Networking → Security Lists → Default Security List

Add Ingress Rule:

B. Server OS Firewall (Persistent)

Run on the host VM (not inside Docker):

sudo iptables -I INPUT 6 -p tcp --dport 5432 -j ACCEPT
sudo netfilter-persistent save

3. Dokploy – PostgreSQL with SSL & WAL 🐳

This setup uses a PostgreSQL 17 image with SSL preconfigured and enables logical replication (required for Prisma Pulse, CDC, etc.).

services:
  postgres-db:
    image: ghcr.io/railwayapp-templates/postgres-ssl:17
    restart: always
    environment:
      POSTGRES_USER: ${POSTGRES_USER:-my-pg-user}
      POSTGRES_PASSWORD: ${POSTGRES_PASSWORD:-my-pg-password}
      POSTGRES_DB: ${POSTGRES_DB:-my-pg-db}
    command:
      - "postgres"
      - "-c"
      - "wal_level=logical"
      - "-c"
      - "max_replication_slots=10"
      - "-c"
      - "max_wal_senders=10"
    volumes:
      - postgres_data:/var/lib/postgresql/data
    ports:
      - "5432:5432"
    networks:
      - dokploy-network

networks:
  dokploy-network:
    external: true

volumes:
  postgres_data:

4. Initial Connection & Verification 🔌

Connect from Local Machine

psql postgresql://my-pg-user:***@pg.ahmedlotfy.site:5432/my-pg-db

Expected:

• ✅ SSL connection

• ✅ Server responds (no timeout)

5. Multi-Tenant Architecture (Users & Databases) 🏗️

Each project gets:

• One database

• One dedicated user

• Schema-level privileges

This avoids cross-project access and supports Prisma migrations.

6. Create Users & Databases 👤📦

Run while connected as the main Postgres admin user.

Example Projects Created

CREATE USER database_user WITH PASSWORD 'secure_password';
CREATE DATABASE example_db OWNER example_user;
GRANT ALL PRIVILEGES ON DATABASE example_db TO myportfolio_user;

🔐 Best Practice
Use strong unique passwords per user (later rotated).

7. REQUIRED: Schema-Level Permissions (Very Important ⚠️)

Without this, Prisma / migrations will fail even if DB ownership is correct.

Step 1: Connect to Target Database

\c zamalek_store_db

Step 2: Grant Schema Access

GRANT USAGE ON SCHEMA public TO example_user;

Step 3: Grant Table & Sequence Permissions

GRANT ALL PRIVILEGES ON ALL TABLES IN SCHEMA public TO example_user;
GRANT ALL PRIVILEGES ON ALL SEQUENCES IN SCHEMA public TO example_user;

Step 4: Auto-Grant for Future Tables (Migrations)

ALTER DEFAULT PRIVILEGES IN SCHEMA public
GRANT ALL ON TABLES TO example_user;

ALTER DEFAULT PRIVILEGES IN SCHEMA public
GRANT ALL ON SEQUENCES TO example_user;

✅ This ensures new tables created by Prisma automatically work.

8. Connection String 🔗

Use this format everywhere (apps, Prisma, migrations):

postgresql://user:***@pg.ahmedlotfy.site:5432/db_name?sslmode=require

9. Data Migration (Local → Server) 🚚

Safest way to migrate across Postgres versions:

docker run --rm -i postgres:17-alpine psql \
"postgresql://user:***@vps-ip-or-domain:5432/db_name?sslmode=require" \
< your_local_dump.sql

10. Verification Checklist ✅

Run these inside psql:

✅ Final Result

You now have:

• 🔐 SSL-secured PostgreSQL

• 🧱 Isolated multi-tenant databases

• 🔄 Prisma-ready permissions

• ☁️ OCI + Dokploy hardened setup

• 🧠 A reusable playbook for future projects
